CE Ultrasonic Transducer Cavitation Vibration Rod For Biochemistry Industry

CE Ultrasonic Transducer Cavitation Vibration Rod For Biochemistry Industry

Large Image :  CE Ultrasonic Transducer Cavitation Vibration Rod For Biochemistry Industry

Product Details:

Place of Origin: CN
Brand Name: CCWY
Certification: CE ROSH TUV
Model Number: CCWY

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Packaging Details: CARTON
Delivery Time: On stock
Payment Terms: T/T
Supply Ability: 20.000.000 PER MONTH
Detailed Product Description



Ultrasonic Cavitation Vibration Rod In Biochemistry , Chemical And Pharmaceutical Industry



1, ultrasonic cavitation around the vibration rod, ultrasonic energy is very uniform distribution around the rod;

2. The output power of 2, ultrasonic vibration rod is not affected by the influence of tank level, capacity and temperature load change, power output is stable and uniform;

3 , ultrasonic vibration rod is more than 1.5 times the service life of traditional ultrasonic vibration plate;

4, ultrasonic vibration stick round tube design can make vibration stick installation convenient use;

5, ultrasonic vibration rod seal waterproof, safe use.



Description:

Since cavitation occurs on all outside areas of the tube, ultrasonic energy distribution in the tank

is very uniform, with an excellent cleaning effect.

The output power of the tubular transducer equipment is not affected by the depth of solution, capacity

of bath,

variation of solution temperature and so on.

Thanks to structural tubular equipment, the application range is wider than a conventional transducer

equipment. It is best matched to vacuum and high pressure cleaning and chemical processing.

It has one and half to two times the life can be maintained compare with conventional transducer

equipment.

The round shape makes it possible to install very simply in every place so that the designing of the

bath is

simple.

The tube structure guarantees watertightness.



Applications:

It is widely used in the fields of ultrasonic cleaning, biochemistry, food, chemical and pharmaceutical

industry.

In biochemistry industry, the tubular transducer equipment can be used for emulsification, separation,

homogenization, refining and catalyzing reaction and it can increase production capacity.

The tubular transducer equipment plays an important role in the even stirring of homogenates

in food processing. In the chemical industry, it is suitable for cleaning pipeline, tanks and kettles.

The catalyzing effect of ultrasonic is quite obvious when the tubular transducer equipment used

in the refinement of scavenge oil and palm oil to biodiesel, as the efficiency can be improved more than

tenfold. Therefore, it will have expansive applications in the petro-chemical industry.



CE Ultrasonic Transducer Cavitation Vibration Rod For Biochemistry Industry



Company introduction:

Established in 1999, Beijing Cheng-cheng Weiye Science and Technology Co., Ltd is a professional

manufacturer in ultrasonic transducers,

ultrasonic equipment and piezoelectric ceramics.

Notably in 2004, we researched and developed our ultrasonic tubular transducer equipment into a

new product that turns the extreme inconvenience brought about by pipeline and vacuum cleaning into

an easy task. This product has been widely used in distillation, mix and mill for various chemical

procedures and has received much praise from our customers.



Payment:

We accept paypal or T/T, western union etc.



Shipping:

Normally if your quantity is not too much, we ship out by Fedex express economy. Or as your

requested by sea or other express, according to your quantity.



Certification:



CE, ISO9001, ROSH



CE Ultrasonic Transducer Cavitation Vibration Rod For Biochemistry Industry
