Piezoelectric Ceramic Discs Ultrasonic Detectors Piezoceramic Ring

Piezoelectric Ceramic Discs Ultrasonic Detectors Piezoceramic Ring
Piezoelectric Ceramic Discs Ultrasonic Detectors Piezoceramic Ring Piezoelectric Ceramic Discs Ultrasonic Detectors Piezoceramic Ring

Large Image :  Piezoelectric Ceramic Discs Ultrasonic Detectors Piezoceramic Ring Get Best Price

Product Details:
Place of Origin: CN
Brand Name: CCWY
Certification: CE ROSH TUV
Model Number: CCWY
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: $3--$15
Packaging Details: CARTON
Delivery Time: On stock
Payment Terms: T/T
Supply Ability: 20.000.000 PER MONTH
Detailed Product Description
High Light:

piezo ceramic disc

,

piezoceramic ring

30/10/5 disc Piezoelectric Ceramic



Quick Detail



30/10/5 disc Piezoelectric Ceramic:

all kinds of piezoceramics and piezoelectric ceramic.we can produce according to the required size.

the materials have the pzt4,pzt5 ,pzt8 or other required material.



Description



30/10/5 Piezoelectric Ceramic:

◊ High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.

◊ High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.

◊ Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.

◊ Good construction: fastened by bolt, easy for assembling, high reliability.





Applications



30/10/5 Piezoelectric Ceramic:

widely used in all kinds of ultrasonic sensor.ultrasonic transducer.Medical,ultrasonic detectors and so on





Specifications





30/10/5 Piezoelectric Ceramic:

Size (mm)
diameter×thickness

The main technical characteristics

fr(MHz)

Zr(Ω)

Kr

φ30/φ10×5

50

0.43

≥0.47





Competitive Advantage



 disc Piezoelectric Ceramic:

◊ High efficiency

◊ High amplitude:

◊ Good heat resistance

◊ Good construction:
