Pipe Cleanning Ultrasonic Vibration Transducer High Power With ROSH

Pipe Cleanning Ultrasonic Vibration Transducer High Power With ROSH

Large Image :  Pipe Cleanning Ultrasonic Vibration Transducer High Power With ROSH

Product Details:

Place of Origin: CN
Brand Name: CCWY
Certification: CE ROSH TUV
Model Number: CCWY

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: $700
Packaging Details: CARTON
Delivery Time: On stock
Payment Terms: T/T
Supply Ability: 20.000.000 PER MONTH
Detailed Product Description

Pipe Cleanning Ultrasonic Vibration Transducer High Power With ROSH







Specifications:



NO. Type Length

(mm)
Weigh

(g)
Frequency

(KHz)
Resonance
Impedance
(Ω)
Static
Capacity
(pF)±10%
Input
Power
(W)
1 CCH-6845D-20LA PZT-8 95 910 20 20-40 5000 100
2 CCH-6850D-28LB PZT-4 67 666 28 10--25 7000 120
3 CCH-6845D-28LA PZT-8 66 625 28 10--25 5000 100
4 CCH-6845D-28LB PZT-4 66 624 28 10--25 6600 100
5 CCH-5838D-25LB PZT-4 76 524 25 10--25 5400 60
6 CCH-5938D-25LA  PZT-8 65 525 25 10--25 3800 60
7 CCH-5938D-28LB  PZF-4 66 510 28 10--25 3800 60
8 CCH-4535D-28ZB
PZT-4
82 425 28 10--25 4100 50
9 CCH-6845D-30L
PZT-8
61 550 30 10--25 5000 100
10 CCH-4838D-33LA  PZT-8 58 420 33 10--25 3800 60
11 CCH-5038D-40LA  PZT-8 54 300 40 10--25 3800 60
12 CCH-4535D-40LB PZT-4 57 300 40 10--25 4100 50
13 CCH-4838D-40ZB
PZT-8
56 310 40 10--25 3800 60
14 CCH-4838S-50LA  PZT-4 40 160 50 30-60 2100 30
15 CCH-3830D-54LA PZT-4 36 135 54 10--25 3200 35
16 CCH-4938D-68ZB PZT-8 79 535 68 15-30 3800 60
17 CCH-5250D-68ZB PZT-4 67 588 68 15-30 7000 120
18 CCH-4038D-80ZB PZT-4 53 290 80 15-30 5400 60
19 CCH-4838D-120ZB PZT-4 57 255 120 15-30 5400 60
20 CCH-4535D-135ZB PZT-4 28 215 135 15-30 4200 50
21 CCH-5038D-25(40)LB PZT-8 65 442 25 and 40 15-30 3800 60
22 CCH-3830D-200LA  PZT-4 42 135 200 15-30 3200 30



Company introduction:



We are dedicated to research and development in the ultrasonic field



Established in 1999, Beijing Cheng-cheng Weiye Science and Technology Co., Ltd is a professional manufacturer specializing in ultrasonic transducers, ultrasonic apparatus and piezoelectric ceramics.



Notably in 2004, we researched and developed our ultrasonic tubular transducer equipment into a new product that turns the extreme inconvenience brought about by pipeline and vacuum cleaning into an easy task. This product has been widely used in distillation, mix and mill for various chemical procedures and has received much praise from our customers.



Our headquarter is located in Beijing, China. Our manufacturing base is in Baoding, Hebei province. Cheng-cheng Weiye also has two branches in Shenzhen and Zhangjiagang and two sales agents in Japan and the USA. At present, there are five departments of the company comprising R&D, Production, Domestic Sale, Export and After-sales service.



Payment:



We accept paypal or T/T, western union etc.





Shipping:

Normally if your quantity is not too much, we ship out by Fedex express economy. Or as your requested by sea or other express, according to your quantity.



Certification:



CE, ROSH, ISO9001



Company pictures:





Pipe Cleanning Ultrasonic Vibration Transducer High Power With ROSH





Our service:



Your inquiry related to our product & price will be replied within 24hours.

  • Well-trained & experienced staff are to answer all your inquiries in English of course.
  • Working time: 8:30am - 6:00pm, Monday to Friday (UTC+8).
  • OEM & ODM projects are highly welcomed. We have strong R&D team here to help.
  • Your business relationship with us will be confidential to any third party.
  • Good after-sale service offered, please get back if you got question.
