Ultrasonic Frequency Impedance Analyzer For Medical Ultrasonic Transducer Electromechanical Coupling
Electromechanical Coupling and Mechanical Quality Factor and Dynamic Inductance
All parameter, graphics
to 600 scan dots)
to 600 scan dots)
Ultrasonic equipment testing,
ultrasonic cleaning, ultrasonic welding,
inspection production line of piezoelectric ceramic below 1mhz
Frequency Range: 1KHZ-1MHz
Min.Frequency Step: 0.1HZ
Measurement accuracy: < 0.5%
Measurement speed: five seconds per pieces(equivalent to 600 scan dots)
Frequency accuracy: ±5ppm
Phase Accuracy: 0.15 degree
Enviroment temperature: 10-40 cº
Impedance Range: 1Ω～1MΩ
Frequency step: less than 1MHZ
Resonance Frequency: Fs
Half Power Frequency: F1 and F2
Maximum real admittance at Fs: Gmax
Dynamic Resistance: R1
Anti resonance frequency: Fp
Mechanical quality factor: Qm
Free capacitance: CT
Dynamic inductance: L1
Dynamic capacitance: C1
Static capacitance: Co
electromechanical coupling coefficient: Keff and Kp
Maximum real impedance at Fp: Zmax
