35/15/5 ring Piezoelectric Ceramic pzt 4 for cleaning

1PCS
MOQ
$50--$120
Price
35/15/5 ring Piezoelectric Ceramic pzt 4 for cleaning
Features Gallery Product Description Request A Quote
Features
Specifications
High Light:

piezoelectric element

,

piezoelectric ceramics

Basic Infomation
Place of Origin: CN
Brand Name: CCWY
Certification: CE ROSH TUV
Model Number: CCWY
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: On stock
Payment Terms: T/T
Supply Ability: 20.000.000 PER MONTH
Product Description

35/15/5 Ring Piezoelectric Ceramic



Quick Detail of 35/15/5Ring Piezoelectric Ceramic:

all kinds of piezoceramics and piezoelectric ceramic.we can produce according to the required size.

the materials have the pzt4,pzt5 ,pzt8 or other required material.



Description of 35/15/5 Ring Piezoelectric Ceramic:



◊ High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.

◊ High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.

◊ Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.

◊ Good construction: fastened by bolt, easy for assembling, high reliability.



Applications of 35/15/5Ring Piezoelectric Ceramic:



widely used in all kinds of ultrasonic sensor.ultrasonic transducer.Medical,ultrasonic detectors and so on





Specifications of 35/15/5 Ring Piezoelectric Ceramic:



Dimensions

(mm)

Capacity

C(pF)

        Weak field dissipation

Tgδ (12v)

  Radial frequency

Fr (KHz)

   Resonance impedance

Zm ()

Coupling modulus

Kp (%)

Φ35Φ155

1750±15%

≤0.5%

43.8±5%

≤20

≥39





Competitive Advantage of Ring Piezoelectric Ceramic:



◊ High efficiency

◊ High amplitude:

◊ Good heat resistance

◊ Good construction:
