35/16/5 PZT4/PZT5/PZT8 piezo disc
35/16/5 disc Piezoelectric Ceramic
Quick Detail
35/16/5 disc Piezoelectric Ceramic:
all kinds of piezoceramics and piezoelectric ceramic.we can produce according to the required size.
the materials have the pzt4,pzt5 ,pzt8 or other required material.
Piezo disc Pzt 4 Piezoelectric Ceramic Discs For Ultrasonic Transducer
Description
35/16/5 Piezoelectric Ceramic:
◊ High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.
◊ High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.
◊ Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.
◊ Good construction: fastened by bolt, easy for assembling, high reliability.
Applications
widely used in all kinds of ultrasonic sensor.ultrasonic transducer.Medical,ultrasonic detectors and so on
Specifications
35/16/5 Piezoelectric Ceramic:
|
Size (mm) |
The main technical characteristics |
||
|
fr(MHz) |
Zr(Ω) |
Kr |
|
|
φ35/φ16×5 |
0 |
0.43 |
≥0.47 |
Competitive Advantage
disc Piezoelectric Ceramic:
◊ High efficiency
◊ High amplitude:
◊ Good heat resistance
◊ Good construction:
