8/25 Piezo Ceramic Disc pzt 5 piezoelectric disk Good heat resistance

1PCS
MOQ
$2--$10
Price
8/25 Piezo Ceramic Disc pzt 5 piezoelectric disk Good heat resistance
Features Gallery Product Description Request A Quote
Features
Specifications
High Light:

piezo ceramic disc

,

piezoceramic ring

Basic Infomation
Place of Origin: CN
Brand Name: CCWY
Certification: CE ROSH TUV
Model Number: CCWY
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: On stock
Payment Terms: T/T
Supply Ability: 20.000.000 PER MONTH
Product Description

8/25 Piezo Ceramic Disc pzt 5 piezoelectric disk Good heat resistance



Quick Detail of 8/25 disc Piezoelectric Ceramic:

all kinds of piezoceramics and piezoelectric ceramic.we can produce according to the required size.

the materials have the pzt4,pzt5 ,pzt8 or other required material.



Description of 8/25 Piezoelectric Ceramic:



◊ High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.

◊ High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.

◊ Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.

◊ Good construction: fastened by bolt, easy for assembling, high reliability.



Applications of 8/25 Piezoelectric Ceramic:



widely used in all kinds of ultrasonic sensor.ultrasonic transducer.Medical,ultrasonic detectors and so on





Specifications of 8/25 Ring Piezoelectric Ceramic:



dimension (mm)

maximal displacement
(um)

load weight
(kg)

drive voltage
 (VDC)

(um)

Φ8×25

≥10

10

0-300

≤0.05





Competitive Advantage of disc Piezoelectric Ceramic:



◊ High efficiency

◊ High amplitude:

◊ Good heat resistance

◊ Good construction:
