Product Description

Non-touched Sonicator Cell Disruptor / Ultrasonic Probe Sonicator




The ultrasonic cell disruptor can prepare emulsoid of 1/100 micron, homogenize mixture

hard to be mixed polymerize some matters and separate out some other.

Generally speaking, it can process various functions such as distillation, smash,

emulsification, homogenization, soliquoid, aberrance, aerosol,quicken up exsolution and crystallization

and preparing different kinds of biological samples under an electron microscope.

Disposing of organic and inorgani compound safely and efficiently

Mainly used for crush of virus and bacterium of the cell and tissue of the various of animal or plant,

crush and combination again of the various of inorganic compound.

Used in emulsification,separation, even,recovering and chemical reaction acceleration etc.

Widely used in the field of biochemistry,microbiology, pharmacology,medicine and etc.



Type: CCH-3538L-20

Full-length(mm): 310

Frequency(KHZ): 20

Resonnce Impedance: 15-30

Capacity (pF)±10%: 10000

Power(W): 750


Type: CCH-1624F-20

Full-length(mm): 310

Frequency(KHZ): 20

Resonnce Impedance: 15-30

Capacity (pF)±10%: 4000

Power(W): 100






1. The digital display and control, convenient and accurate.


2. Regular time setting button (4), the left two keys to set minutes of increase and decrease,

    the right of the two key set seconds of increase and decrease

3.The "Pulse" : works display window. In the intermittent work way is divided into two parts:

  the left two shows that intermittent way. Pulse width, the range of 0.1 ~ 9.9 seconds,

  by ", "said. In "continuous" works shows the "Cont."

4. The intermittent work way of "duty cycle" set button.

 Two key set for intermittent mode pulse width on the left.

 Two key way of intermittent intermittent time setting key on the right.

5.Mode ": continuous output work Mode or" pulse output "work Mode selection button.

   Remark: use the intermittent work way can prevent the accumulation of excessive heat in the liquid,

   and because the material to be able to accumulate after each pulse cluster probe oscillator,

   so can provide a more effective treatment results.

6. “Start/Stop” Work start or stop button.

7. “Intensity display”:The intensity of ultrasonic output display window, display range of 0 ~ 100%.

8. “Max.intensity”:Ultrasonic output intensity limit knob, a total of 4, 20%, 35%, 60% and 100% respectively.

    Note: as a strong power output will damage the amplitude of small diameter,

   so please select a location according to the following requirements:

9. “Intensity” :Ultrasonic output intensity, can be in "the intensity of ultrasonic

   output restrictions" knob selected range from 0 ~ 100% range adjustment.

10. “Tune” :Ultrasonic output frequency tracking finetuning hole, generally do not need to adjust,

    but after the user to replace the amplitude may need to be adjusted a little.

11.“Stand by”: Overheating protection lamp, when the temperature sensor is detected

  by the temperature too high, the indicator light will flash, the host will cease to work,

  the normal work of the host, the indicator light is not bright.

12: "POWER" : the POWER switch, from one side of the "ON" to connect the POWER,

   ON the other side to shut off the POWER.



Specification parameter



Type           Power(w )  Optional luffing rod       Handle Sample Weight        Plus duty cycle work

UH-100A      100        1/8″3/16″1/4″                 100ul~ 80ml                            1%~99%

UH-250A      250        1/8″3/16″1/4″                100ul~ 200ml                            1%~99%

UH-500A      500        1/8″3/16″1/4″1/2″          250ul~ 500ml                            1%~99%

UH-800A      800        3/16″1/4″1/2″3/4″          250ul~ 800ml                            1%~99%

UH-950A      950        3/16″1/4″1/2″3/4″          250ul~ 1000ml                          1%~99%

UH-1200A    1200       3/16″1/4″1/2″3/4″          50ml~ 1200ml                           1%~99%
