CE Triple Frequency 40khz / 80khz / 120khz Transducer , ultrasonic generator
Quick Detail
three frequency ultrasonic transducer
Piezoelectric transducer uses the piezoelectric effect to realize transduction between electric and sound energy. It comprises a radiation head, electrode, cap, prestressed bolt, piezoelectric chip and an insulating tube.
Description
Ultrasonic cleaning transducer uses the piezoelectric effect to realize transduction between electric and sound energy. It comprises a radiation head, electrode, cap, prestressed bolt, piezoelectric chip and an insulating tube. The piezoelectric transducer is widely used in ultrasonic cleaning machine and high-power industry cleaning devices.
Ultrasonic cleaning machine working principle is what kind of? Here we introduce the main aspects of the work and steps, ultrasonic cleaning machine Principles and knowledge of work.
The principle of ultrasonic cleaning machine is mainly to transducer Energy, power ultrasonic frequency source,
And to be converted into mechanical vibration,
After cleaning the tank wall to the cleaning fluid in the channel to the ultrasonic radiation. The micro bubbles in the liquid in the tank can be caused by the radiation of the ultrasonic wave.
Enough to keep vibration under the action of sound waves.
When the sound pressure or sound pressure to a certain extent by the pressure, the bubble will quickly expand,And then suddenly closed. During this process, the bubble is closed and the shock wave is generated.
1012-1013pa
Pressure and office
Temperature, pressure generated by the ultrasonic cavitation can destroy the insoluble dirt and make their differentiation in solution, the steam type cavitation on dirt.
Direct repeated impact.
On the one hand, the adsorption on the surface of the dirt and the cleaning piece can be destroyed, on the other hand, it can cause the fatigue damage of the dirt layer,
Type of gas bubble vibration scrubbing on solid surface pollution layer once the seam can be drilled, bubble immediately drill down vibration causes the pollution layer off, because the air
In the interface, the two liquid is quickly dispersed and emulsified. When the solid particles are covered with oil, the oil is emulsified and fixed on the surface of the cleaning piece.
Body particles themselves fall off, ultrasonic transmission in the cleaning fluid will produce positive and negative alternating pressure, forming a jet, impact cleaning parts, while the non line
The sex effect will produce sound and micro flow, while ultrasonic cavitation in the solid and liquid interface will produce high-speed micro jet, all of these effects can be broken.
To remove or weaken the boundary layer, increase the mixing and diffusion function, accelerate the dissolution of the soluble contaminants, and strengthen the cleaning of the chemical cleaning agent.
Use. It can be seen that the liquid can be dipped into the sound field and the presence of a cleaning effect, the characteristics of the surface is very complex parts of the shape of the parts
Cleaning. In particular, the use of this technology, can reduce the amount of chemical solvents, thereby greatly reducing the environmental pollution.
Specifications
|
Type |
Length (mm)
|
Weigth(g)
|
Frequency(khz)
|
Resonance Impedance(Ω) |
Capacity (Pf)±10﹪
|
Power(w)
|
|
CCH-4040D-40/80/120 KHZ P4 |
56 |
260 |
40/80/120 |
<40 |
5400 |
30 |
Service
Your inquiry related to our product & price will be replied within 24hours.
· Well-trained & experienced staff are to answer all your inquiries in English of course.
· Working time: 8:30am - 5:30pm, Monday to Friday (UTC+8).
· OEM & ODM projects are highly welcomed. We have strong R&D team here to help.
· Your business relationship with us will be confidential to any third party.
· Good after-sale service offered, please get back if you got question.
Company introduction:
Established in 1999, Beijing Cheng-cheng Weiye Science and Technology Co., Ltd is a professional
manufacturer in ultrasonic transducers, ultrasonic equipment and piezoelectric ceramics.
Notably in 2004, we researched and developed our ultrasonic tubular transducer equipment into a new product that turns the extreme inconvenience brought about by pipeline and vacuum cleaning into an
easy task. This product has been widely used in distillation, mix and mill for various chemical procedures and has received much praise from our customers.
Payment:
We accept paypal or T/T, western union etc.
Shipping:
Normally if your quantity is not too much, we ship out by Fedex express economy. Or as your requested by sea or other express, according to your quantity.
Certification:
CE, ISO9001, ROSH
