Piezoelectric Element Piezo Ceramic Plate 2200pF For Automatic Ultrasonic Cleaner

Piezoelectric Element Piezo Ceramic Plate 2200pF For Automatic Ultrasonic Cleaner

Piezoelectric Element Piezo Ceramic Plate 2200pF For Automatic Ultrasonic Cleaner supplier Piezoelectric Element Piezo Ceramic Plate 2200pF For Automatic Ultrasonic Cleaner supplier Piezoelectric Element Piezo Ceramic Plate 2200pF For Automatic Ultrasonic Cleaner supplier

Large Image :  Piezoelectric Element Piezo Ceramic Plate 2200pF For Automatic Ultrasonic Cleaner

Product Details:

Place of Origin: CN
Brand Name: CCWY
Certification: CE ROSH TUV
Model Number: CCWY

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: $50--$120
Packaging Details: CARTON
Delivery Time: On stock
Payment Terms: T/T
Supply Ability: 20.000.000 PER MONTH
Detailed Product Description



32/12/5 Ring Piezoelectric Ceramic



Quick Detail



32/12/5Ring Piezoelectric Ceramic:

all kinds of piezoceramics and piezoelectric ceramic.we can produce according to the required size.

the materials have the pzt4,pzt5 ,pzt8 or other required material.

Piezoelectric Element Piezo Ceramic Plate 2200pF For Automatic Ultrasonic Cleaner



Description



32/12/5 Ring Piezoelectric Ceramic:

◊ High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.

◊ High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.

◊ Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.

◊ Good construction: fastened by bolt, easy for assembling, high reliability.





Applications



widely used in all kinds of ultrasonic sensor.ultrasonic transducer.Medical,ultrasonic detectors and so on





Specifications



32/12/5 Ring Piezoelectric Ceramic:

Dimensions

(mm)

Capacity

C(pF)

  Weak field dissipation

Tgδ (12v)

   Radial frequency

Fr (KHz)

  Resonance impedance

Zm (∩)

Coupling modulus

Kp (%)

Φ32xΦ15x5

2200±15%

≤2.0%

40.8±5%

≤250

≥45





Competitive Advantage of Ring Piezoelectric Ceramic:



◊ High efficiency

◊ High amplitude:

◊ Good heat resistance

◊ Good construction:
