High Power 100w Ultrasonic Cleaning Transducer , Vibration Piezoelectric Transducer Sensor

1PCS
MOQ
High Power 100w Ultrasonic Cleaning Transducer , Vibration Piezoelectric Transducer Sensor
Features Gallery Product Description Request A Quote
Features
Specifications
Item: CCH-6845D-20LA Pzt-8
Length(mm): 94
Weight(g): 900
Frequency(KHZ): 20
Resonance Impedance: 10-20 Ω
Input Power(w): 100
High Light:

underwater ultrasonic transducer

,

40khz ultrasonic transducer

Basic Infomation
Place of Origin: CN
Brand Name: CCWY
Certification: CE ROSH TUV
Model Number: CCWY
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: On stock
Payment Terms: T/T
Supply Ability: 20.000.000 PER MONTH
Product Description



High Power 100w Ultrasonic Cleaning Transducer , Vibration Piezoelectric Transducer Sensor



High power 100w Ultrasonic Cleaning vibration Transducer Sensor





Quick Detail



28khz 100w ultrasonic cleaning transducer:

Piezoelectric transducer uses the piezoelectric effect to realize transduction between electric and sound energy. It comprises a radiation head, electrode, cap, prestressed bolt, piezoelectric chip and an insulating tube.



The function of ultrasonic transducer is to convert the input electric power into mechanical power (ultrasonic wave) and then transmit it, but it consumes a little part of power.
The technical problem of ultrasonic transducer is to design an ultrasonic transducer with large operating distance and wide frequency band.
The transducer consists of a shell, a matching layer, a piezoelectric ceramic disc transducer, a backing, a leading cable, and a Cymbal array receiver. The piezoelectric ceramic disk transducer is made of PZT-5 piezoelectric material with polarization in thickness direction. The Cymbal array receiver consists of 8~16 Cymbal transducers, two metal rings and a rubber washer. The distance of the invention is greater than 35m, and the bandwidth is 10kHz, which can detect the moving target with high speed.





Applications



widely used in ultrasonic cleaning machine and high-power industry cleaning devices.



Naming methods as following:



High Power 100w Ultrasonic Cleaning Transducer , Vibration Piezoelectric Transducer Sensor 0



High Power 100w Ultrasonic Cleaning Transducer , Vibration Piezoelectric Transducer Sensor 1



Specifications



20khz100w ultrasonic cleaning transducer:



Type

Length



(mm)

Weigh



(g)

Frequency



(KHz)

Resonance

Impedance

(Ω)

Static

Capacity

(pF)±10%

Input

Power

(W)

CCH-6845D-28LB

PZT-4

66

624

28

10-20

6600

100







Company introduction:

Established in 1999, Beijing Cheng-cheng Weiye Science and Technology Co., Ltd is a professional manufacturer in ultrasonic transducers, ultrasonic equipment and piezoelectric ceramics.

Notably in 2004, we researched and developed our ultrasonic tubular transducer equipment into a new product that turns the extreme inconvenience brought about by pipeline and vacuum cleaning into an easy task. This product has been widely used in distillation, mix and mill for various chemical procedures and has received much praise from our customers.

Payment:

We accept paypal or T/T, western union etc.

Shipping:

Normally if your quantity is not too much, we ship out by Fedex express economy. Or as your requested by sea or other express, according to your quantity.

Certification:

CE, ISO9001, ROSH



High Power 100w Ultrasonic Cleaning Transducer , Vibration Piezoelectric Transducer Sensor 2
